Paired with the Ventrac Winter Cab, the KD Blade makes clearing driveways a warm, comfortable job. Push snow with precision on pavement while staying protected from wind and cold.
Angle the KD Blade 30° to push heavy snow off driveways and sidewalks efficiently in winter storms.
With the blade locked, the KD Blade backfills and levels earth while pushing debris out of the way.
Perfect for contractors moving soil, gravel, or loose material then grading to a leveled finish with the KD Blade’s reversible cutting edge.
From clearing snow to grading soil or pushing debris, the KD Blade is built for year-round versatility. Its hydraulic angle control and adjustable skid shoes make it just as effective on winter driveways as it is on summer job sites.
The KD Blade comes in working widths of 48, 60, and 72 inches, giving options for clearing snow, grading ground, or moving material.
Private properties, contractors, municipalities, and property managers alike can benefit from the KD Blade—compact in size but tough enough for driveways, sidewalks, trails, and jobsite clean-up.
Length (27 in) and height (22 in) make the KD series robust yet manageable for storage and transport.
With a ground clearance of 13 inches at 0° angle and a durable frame, the KD Blade is built for both snow removal and material pushing.
With hydraulic angle left/right (up to 30°) and the SDLA control, the KD Blade allows precise control for grading, leveling, or plowing.
Ventrac KD Power Angle Blades have working widths of 48, 60, and 72 inches (122, 152, 183 centimeters). All control functions are performed with the S.D.L.A. control for raising and lowering the blade or angling it left or right. Adjustable skid shoes accommodate dozing at selected heights, such as moving snow on gravel driveways.
The blades can be operated in a trip position for plowing or in a locked position for digging into material.
Ventrac Power Angle Blades are versatile, labor-saving attachments designed for any number of jobs. From grading, leveling, and backfilling ground to plowing snow, moving material, or cleaning an area, the Ventrac KD series blades are up to the task.
Base Specifications
| Info | |
|---|---|
|
Product Image
|
|
|
Model
|
|
|
Description
|
72" Dozer Blade
|
|
Product Type
|
|
|
Sku
|
39.55253
|
|
Price
|
$2,360
|
| General | |
|
Max Angle (Left/Right)
|
30°
30°
|
|
Ground Clearance
|
13in @ 0 deg.
33.02cm @ 0 deg.
|
|
Skid Shoes
|
adjustable cast iron skid shoe discs
|
|
Spring Trip
|
Mechanical On/Off
|
|
Hydraulic Cylinder Bore and Stroke
|
2in x 8in
5.08cm x 20.32cm
|
|
Hydraulic Power Angle
|
|
| Dimensions | |
|
Front Mount
|
|
| Dimensions | |
|
Length
|
27in
68.58cm
|
|
Overall Width
|
72in
182.9cm
|
|
Height
|
22in
55.88cm
|
|
Weight
|
225lb
102.1kg
|
|
Working Width
|
72in
182.9cm
|
|
Working Width 30°
|
62in
157.5cm
|
- Attachment Width
- 72in
- Area Cleared
- Time
- Area Cleared
- Time
